Black Top Coat PPF TPH

Black Top Coat PPF TPH



Basic Info.

Model No.	TPH PPF	Warranty	1 years
Type	Black Top Coat PPF TPH	Material	TPH
Structure	3 Layers	Glue	Henkel/Ashland
Thickness	8 mil or customized	Size	1.52m*15m(can be customized)
Feature1	Protect Paint	Feature2	Self-healing Coating
Feature3	Improved Gloss	Feature4	Stain Resistance
OEM	Support	MOQ	None MOQ
Logo Print	Available	Transport Package	Standard Export Packing
Sample	2 meters sample for free	Trademark	No
Origin	China	HS Code	3919909090
Production Capacity	1,500,000 meters per month	Brand	Dingxin Films



※ Products Structure

※ Product Description

1. Product Features







    Dingxin Paint Protection Film (PPF) is a premium soft PVC (TPH) with a clear, stable pressure sensitive adhesive system, designed to provide the best overall properties to protect the paint or other smooth surface from stone, stain, abrasion or impact. Black finish matching most factory matte paints that can transform glossy vehicle paint to clear black.

    For our PPF(TPH), we can also make the top coating with Glossy and matte type, with high self-healing ability and good cost performance. Our products are already entered in European market, North American market and so on. If anything interests, please kindly contact with us.



2. Quality comparison and advantage





Advantage:

* PROTECT PAINT

Our sophisticated technology provides a dense top coat that heals faster than most PPF brand on the market and a beautiful crystal-clear finish that anti-yellows or cracks for at least 1 years. These extremely durable films safeguard any vehicles paint from airborne impurities, common scratches, and road debris damage.

* SELF-HEALING COATING

The ability to heal is an advanced feature inside the films coating called (TPH), a flexible thermoplastic layer that can self-heal once damage occurs. Slight abrasions, scratches or outdoor hazards can be easily averted with these time-tested products.

* IMPROVED GLOSS

As light passes through the film it illuminates the paint color giving it a shiny glazed appearance. Silicone elements in the substrate also enhance the original paint producing a smooth high-gloss finish.

* STAIN RESISTANCE

The anti-stain protection comes from polyurethane dispersion (PUD), which is a self-cross-linking technology that enhances coating properties, such as hardness, water, and solvent resistance.



    Our paint protection film protects vehicle exteriors from scratches and minor damage. It has the unique characteristic of restoring itself from slight scratches and accidental marks. Healing properties activate at room temperature, or from sunlight. A virtually invisible protective layer seals the paint color in and prevents staining. This coverage adds value, preserving the vehicle's original, shiny new look.



SGS testing report:



3. Detail Description

Test Item	Standard	Test Method
	TPH
Modulus of Elasticity	≤500Kgf/cm²	Tension tester
Initial Stripping Force	≥5N	Stick the steel plate for 20 minutes, with Tension tester
Sustained Adhesion	8N~20N	Stick the steel plate for 168 hours, with Tension tester
Coating Elongation	≥100%	Electronic tension tester
Self-healing Ability	≤5S	Brass brush, 750g, 10 times wipe, 60℃ condition
Coating Adhesion	5B	Grid testing
Scrath Resistance	No scratch	Brass brush, 750g, 10 times wipe
Resistance to Gasoline, Acid and Base	No abnormalities	Soak in alkaline water(PH=9) for 30min
Weather resistance test	ΔE＜2	QUV Tests：≥1200H(TPH)
Cold and Warm resistance	No Cracks No Bubbles	High and low temperature box: -40℃ and 80℃ alternating test for 168H



4. Installation Step



Step:

(1) Clean the car surface.

(2) Take out the film and contrast the approximate location.

(3) Peel off the back film gently and spray a little water added on the sticky side.

(4) Spray a little water added on the Car surface.

(5) Place the film on the car area in a good position,Align with the edges and adjust the position.

(6) Use a scraper to remove the water from the inside.

(7) Scrape the moisture off the edges thoroughly,Then let it sit for 24 hours.



5. About our company and factory





• OUR HISTORY

    Started in the year 2016, Dingxin Films has become the biggest window films and PPF manufacturer in North China, and one of the leading solar film producer in China. Now our business has covered almost all over the world, including North America, Europe, Middle east area, South America and so on, with over 10 million USD annual turnover.





• OUR FACTORY

    Our factory is located Fenyang City of Shanxi province, Covers 15,000 square meters' workshop, the output can be up to 1,200,000 meters per month.

    Dingxin is an industry leader in solar control window films, paint protection film solutions for a variety of applications and industries including automotive, architectural and safety/security. Through the continuous innovation and dedication to R&D, manufacturing process and quality control, we are providing the solar control window films and paint protection films with the highest quality and performance in the industry.

    With a wide range of colors and qualities, all of our solar window films and ppf are manufactured from the high quality raw material which meet the demands of our global clients. We currently serving hundreds of partners worldwide and have rapidly expanded our business to more markets. Dingxin is also recognized as an excellent qualified OEM provider for many famous brands window film and PPF products.

    Begin with the year 2020, we have set up a new machine for 1.83(72")width films, and TPU film extrusion line made by Sumitomo, this is the first Chinese manufacturer combined raw material and finished products production.

6.Exhibition show and certification





7. Why choose us



  Solar window film supplies and professional paint protection film manufacturer.

• Experienced Manufacturing

  The first high-end window film manufacturer from Northern China

• Export do dozens of countries

  Only provide best quality products and meet OEM requirements

• Class 1000 dust-free production environment

  Class 1000 dust-free production environment ensures the best quality of our

• 100% after sale service

  Provide high quality,high efficiency and durable products to customers globally



8. Professional packing and shipment





• Packing:

  Air cushion film inside, carton box outside, With plastic pallet and stretch wrap film.

  Carton size 1.6m*0.15m*0.15m .

• Shipment:

  For small order,we can ship within 1-2 days by DHL,UPS,FedEx etc, usually you will receive the items within 5-7 business days.

  For large order,we will ship by sea and usually it takes 15-50 days to arrive.

• Payment: Paypal or TT etc,it is up to you.

9. Product Range



  Quality is priority to us, we provide a variety of automotive window film, residential and commercial film, decorative film, paint protection film to worldwide customers.



10. About Our Service

• OUR SERVICE

    We have a professional Team, including minority language team with German, Spanish and Russia language, to service any request from our customers. After fully understand the customer's request, we will arrange the factory to prepare the order. We have a very wide cooperation with most world famous logistics company, to send the order safety and efficient.



11. Contact Information



Shanxi Dingxin Films Technology Stock Co.,Ltd



Address: No.66 Fenjiu Street, Fenyang City, Shanxi Province, China.

Tel: +86(0)351-5646712

Mob: +86 17735161089

Email: sales@dingxinfilms.com





※FAQ:

Q 1- Are you factory or trading company?
A: We are factory at Shanxi,China.
Q 2-How are the products delivered to us?

A: Small quantity by express, large quantity by sea or air shipment.

Q 3-How much is the delivery time?

A: Normally 20 days for standard products.

Q 4-What is your terms of payment?

A: First cooperation with 100% deposit, begin from second cooperation, we can provide 50% deposit and balance payment before shipment.

Q 5-What is the MOQ?

A: No MOQ for standard products.

Q 6-Whether the products can be made of different standard?

A: Of course yes.We could produce product according to custom need.

Q 7-Can I order the paint protection film using my own brand?
A: Yes, we accept OEM production using your own brand.

Q 8-Do you provide samples?

A: Yes, we can provide samples based on your request, but the transport cost will be on your side.

Q 9-If I don't have any experience in the installation of paint protection film, do you have training service?
A: We can provide some training videos.

Q 10-Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery.

Hot Tags: black top coat PPF TPH, China, suppliers, manufacturers, factory, customized, cheap, pricelist, buy discount, security films, paint protection in transit, long term storage paint protection films, antique car paint protection films, safety films, paint protection for leased cars
